Dead-letter queue

Understand archived jobs, inspect failures, redrive safely, and configure retention.

Headgate’s archived job state is the dead-letter queue (DLQ). There is no second active queue or dead_jobs table. When a job enters archived, it remains in the ordinary job store with the same ID, payload, metadata, attempt history, and errors until its terminal retention expires.

Keeping the dead letter as a state avoids a move between two stores and lets the same bounded inspection and control API search, diagnose, and redrive the job.

archived is not the optional SQL cold archive. An archived job is still hot, inspectable, and redrivable. A cold-archive row is retained for long-term audit after the hot job expires and is not part of normal job inspection or admission.

What enters the DLQ

Cause	Terminal state	Meaning
A returned failure consumes the last permitted attempt	archived	Automatic retries are exhausted
A handler returns skip	archived	The handler deliberately stops retrying
The absolute job deadline elapses	archived	The work is no longer useful

Several terminal-looking states are deliberately separate because they need different operator responses:

State	Why it is not the DLQ	Recovery
quarantined	Repeated crashes identify a possible poison-pill fingerprint	Diagnose the crash and release the fingerprint from Quarantine
undecodable	The payload version or resumable-step definition is incompatible	Deploy an upcaster or compatible handler, or repair the payload
cancelled	An operator intentionally stopped the job	Keep it for audit or enqueue replacement work
deleted	A handler returned revoke, or terminal retention removed the row	It cannot be redriven from Headgate

Returned errors increment attempt; process loss and expired leases increment crash_attempt. A crashing job can therefore reach quarantined without being mislabeled as an ordinary retry-exhausted dead letter.

Inspect archived jobs

In the console, open Jobs, choose the archived state filter, and select a row. The detail sheet keeps the job list visible and shows the error and attempt timeline, payload, metadata, lifecycle, and available actions.

List queries remain payload-free. Request the payload only for the job being diagnosed:

curl 'http://127.0.0.1:8080/api/v1/jobs?state=archived&limit=50'

curl 'http://127.0.0.1:8080/api/v1/jobs/JOB_ID?include_payload=true'

Payloads and metadata may contain personal data or credentials. Protect both the control API and console with operator authentication, and grant payload inspection separately when your application needs a narrower role.

Redrive after fixing the cause

Retry is defined only for archived → available. It preserves the job’s identity, attempt counters, errors, and other history, clears finalization, and makes the job eligible for admission immediately. Because history is preserved, another returned failure can archive it again; redrive is not a way to erase an exhausted retry budget.

For one job, use the Retry action in its console sheet, the CLI, or the control API:

headgatectl --api http://127.0.0.1:8080 jobs retry JOB_ID

curl --request POST \
  --header 'Idempotency-Key: redrive-JOB_ID-1' \
  'http://127.0.0.1:8080/api/v1/jobs/JOB_ID/retry'

For a reviewed set of at most 1,000 jobs, select their checkboxes in the console or send the explicit IDs. The response reports success or failure for each ID:

curl --request POST \
  --header 'Content-Type: application/json' \
  --header 'Idempotency-Key: billing-redrive-2026-08-31' \
  --data '{"action":"retry","ids":["JOB_1","JOB_2"]}' \
  'http://127.0.0.1:8080/api/v1/jobs/actions'

For a larger set, use the asynchronous bulk operation. Start with dry_run: true, review the matched count, then submit the same non-empty selector with a new idempotency key and dry_run: false:

curl --request POST \
  --header 'Content-Type: application/json' \
  --header 'Idempotency-Key: billing-redrive-preview-1' \
  --data '{
    "action":"retry",
    "selector":{"state":"archived","queue":"billing"},
    "dry_run":true
  }' \
  'http://127.0.0.1:8080/api/v1/jobs/bulk'

The bulk route returns an operation ID to poll at GET /api/v1/operations/{id}. Empty selectors are rejected, and the operation processes matches in bounded batches instead of holding one request open for the whole queue depth.

Repair the root cause before redriving. A transient dependency outage may need no job change. Bad input may need PUT /api/v1/jobs/{id}/payload before retry. An incompatible schema belongs in undecodable, not archived, and must be fixed through payload versioning or an upcaster.

Use death handlers for notification

A death handler runs once per successful fence-verified transition to archived. A job that is redriven and later archived again produces a new death event. The handler receives the job snapshot, terminal error, and one of attempts_exhausted, skipped, or deadline_exceeded. Use it for alerts, metrics, or an incident record—not for deciding whether the archive transition is allowed.

Rust

use headgate::{DeathHandlerFn, WorkerConfig};
use std::sync::Arc;

let notify = DeathHandlerFn::new(|event: &headgate::DeathEvent| {
    tracing::error!(
        job_id = %event.envelope().id,
        reason = ?event.reason(),
        error = event.error(),
        "job entered the dead-letter queue"
    );
});

let worker_config = WorkerConfig {
    death_handlers: vec![Arc::new(notify)],
    ..WorkerConfig::default()
};

Death handlers run synchronously in registration order inside the worker, after the durable store write. A process can die after archiving and before sending an external notification, so do not treat the callback as a transactional outbox. Callback code should tolerate application-level duplicates, and durable alerting should reconcile from state=archived inspection.

Choose retention deliberately

retention_ms controls how long a terminal job stays in the hot store. Configure a positive window long enough for your on-call and redrive process; once the hot row is removed, the ordinary retry operation no longer has a job to restore.

PostgreSQL and MySQL can copy selected queues into monthly cold-archive partitions during the bounded retention sweep. Those rows are for audit and later pruning, not admission or redrive. Redis supports terminal retention but does not claim SQL cold-archive partitions.

Storage	Search with state=archived	Redrive	Purpose
Hot archived job	Yes	Yes	Operational DLQ
SQL cold archive	No	No	Long-term audit after hot retention
